Dell 3110CN - Page 63

Maintenance 63
3. Completely remove the seal from the print cartridge by pulling the tab on the end of the print
cartridge.
NOTE: Pull the seal out straight. Pulling the seal diagonally may tear it.
4.
Grasp both handles of the print cartridge with the label facing up and slide the cartridge into
the same color slot. Make sure the cartridge is fully inserted.
