Installing base cover
1 Align the base cover with the screw holders on the computer.
2 Press the edges of the cover until it clicks into place.
3 Tighten the two middle screws.
4 Tighten the M2.5xL8.5 screws to secure the base cover to the computer.
5 Follow the procedure in After working inside your computer.
Battery
Removing the battery
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover
3 To remove the battery:
a Disconnect the battery cable from the connector on the system board [1].
b Remove the M2.0x3.0 screws that secure the battery to the computer [2].
c Lift the battery away from the computer [3].
10
Removing and installing components
