Installing the display assembly
1 Place the display assembly to align with the screw holders on the computer.
2 Tighten the M1.6xL2 screws to secure the display assembly to the computer.
3 Turn over the computer.
4 Connect the display cable to the connector.
5 Place the metal bracket over the display connector and tighten the screw to secure the display cable to the computer.
6 Replace the power port on the system board and tighten the screw to secure it to the display hinge.
7 Route the WLAN card cable to its routing guide on the fan and then reconnect the antenna cables to the WLAN card.
8 Connect the eDP cable to its connector on the system board.
9 Install the:
a battery
b base cover
c microSD card
10 Follow the procedure in After working inside your computer
26
Removing and installing components
