Connection Type Pane
The Connection Type pane is part of the Container Statistics page, and the information displayed in this pane depends
upon the connection type of the selected container:
• NFS containers — lists the following NFS connection configuration information:
– NFS Access Path
– Client Access
– NFS Options
– Map Root to
• CIFS containers — lists the following CIFS connection configuration information:
– CIFS Share Path
– Client Access
• OST or RDS containers — lists the following OST or RDS connection configuration information, grouped under the
following tabs:
– Capacity tab — Status, Capacity, Capacity Used, and Total Images.
– Duplication tab — The Duplication Statistics pane displays both Inbound and Outbound categories with the
following statistic types: Bytes Copies-logical, Bytes Transferred-actual, Network Bandwidth Savings-in
percentage, Current Count of Active Files, and Replication Errors. The Recent Number of Optimized Copies pane
displays a summary table that lists each entry by the following: File Name, Peer IP, Peer ID, Logical Bytes to
Send, Replication Rate, Savings, and Replicated at categories.
– Client Statistics tab — Contains the Client Statistics pane, which displays Images Ingested, Images Complete,
Images Incomplete, Images Restored, Bytes Restored, Image Restore Errors, Image Ingest Errors, Bytes
Ingested, Bytes Transferred, and Network Savings (in percentage) statistics.
For more information, see Monitoring Container Statistics.
Duplication Statistics
The Duplication Statistics pane displays duplication statistics (which are also known as file copy statistics) for OST or
RDS connection type containers. To view these duplication statistics, navigate to the Container Statistics page, select
an OST or RDS connection type container in the Container Name list, and select the Duplication tab. The Duplication
Statistics pane displays the following statistics types:
• Inbound:
– Bytes Copied (logical): displayed in bytes
– Bytes Transferred (actual): displayed in bytes
– Network Bandwidth Savings: (displayed by percentage)
– Current Count of Active Files: displayed in numbers of files
– Replication Errors: displayed in numbers of errors
• Outbound:
– Bytes Copied (logical): displayed in bytes
– Bytes Transferred (actual): displayed in bytes
– Network Bandwidth Savings: (displayed by percentage)
– Current Count of Active Files: displayed in numbers of files
– Replication Errors: displayed in numbers of errors
