Dell E2014T User Manual

10  About Your Monitor
6
7
8
9
Connect the USB cable from the monitor to the
USB upstream port computer to allow you to use the USB ports and
touch screen function on the monitor.
Connect your USB device. You must connect the
USB 2.0 downstream
USB upstream cable to your monitor and computer
ports
before you can use these ports.
Use a security cable to prevent unauthorized
Security cable slot removal of the monitor. (security cable sold
separately)
Use a M3 x 6 mm screw to lock the stand to the
Stand lock
monitor. (screw not included)
Specifications
Panel
Screen type Active matrix - TFT LCD
Panel type TN
Viewable image
Diagonal 49.41 cm (19.5 inches)
Horizontal Active Area 432.00 mm (17.01 inches)
Vertical Active Area 239.76 mm (9.44 inches)
Area 103576.32 mm
2
(160.54 inch
2
)
Pixel pitch 0.27 mm (H) x 0.27 mm (W)
Viewing angle
Horizontal 170 degrees (typical)
Vertical 160 degrees (typical)
Luminance
Panel 250 cd/m
2
(typical)
Monitor 225 cd/m
2
(typical)
Contrast ratio 1000:1 (typical)
Dynamic contrast ratio 8,000,000 : 1
Faceplate coating Anti-glare with hard coating 3H
Bezel gloss 3~5 gloss units
Touch glass gloss >30 gloss units
NOTE: The user should consider the placement of
the display as the reflection of surrounding light and
bright surfaces from the glass may cause
disturbances to users.
Backlight LED edgelight system
Response time 2 ms (with overdrive)
Color depth 16.77 million colors

Dell E2014T Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	2 ms
Display diagonal	19.5 \
Touchscreen type	Tabletop
Display brightness	225 cd/m²
Display resolution	1600 x 900 pixels
Display technology	LED
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	49.4 cm
Viewing angle, horizontal	170 °
Certification	EPEAT Gold\\r TCO
Product color	Black
Display viewable area (HxV)	432.00 x 432.00 mm
Dimensions (W x D x H) with stand	505.9 x 165 x 376 mm
Cables included	AC, HDMI, USB
Tilt angle range	5 - 31 °
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
Package weight	6070 g
Sustainability certificates	ENERGY STAR
NVIDIA G-SYNC	No

Weight and Dimensions

Depth (with stand)	165 mm
Width (with stand)	505.9 mm
Height (with stand)	376 mm
Weight (with stand)	4890 g
Depth (without stand)	51.7 mm
Height (without stand)	311.2 mm
Weight (without stand)	3430 g
