Dell E2014T User Manual

OSD Options
Menu and Submenus Description
Energy Use
This meter shows, in real time, the energy level being
consumed by the monitor.
Use this menu to activate Brightness/Contrast adjustment.
Brightness/Contrast
Brightness
Brightness adjusts the luminance of the backlight
(minimum 0; maximum 100).
Press the
button to increase brightness.
Press the button to decrease brightness.
NOTE: Brightness control is disabled during “Screen dim”
in PowerNap option when screen saver is activated.
Contrast
Press the
button to increase contrast and Press the
button to decrease contrast (between 0 and 100).
Adjust Brightness first, and then adjust Contrast only if
further adjustment is necessary.
Contrast adjusts the difference between darkness and
lightness on the monitor.
Setting Up the Monitor  25

Dell E2014T Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	2 ms
Display diagonal	19.5 \
Touchscreen type	Tabletop
Display brightness	225 cd/m²
Display resolution	1600 x 900 pixels
Display technology	LED
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	49.4 cm
Viewing angle, horizontal	170 °
Certification	EPEAT Gold\\r TCO
Product color	Black
Display viewable area (HxV)	432.00 x 432.00 mm
Dimensions (W x D x H) with stand	505.9 x 165 x 376 mm
Cables included	AC, HDMI, USB
Tilt angle range	5 - 31 °
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
Package weight	6070 g
Sustainability certificates	ENERGY STAR
NVIDIA G-SYNC	No

Weight and Dimensions

Depth (with stand)	165 mm
Width (with stand)	505.9 mm
Height (with stand)	376 mm
Weight (with stand)	4890 g
Depth (without stand)	51.7 mm
Height (without stand)	311.2 mm
Weight (without stand)	3430 g
