Dell E2015HV User Manual

22  About Your Monitor
Color Depth 16.7 mil colors 16.7 mil colors 16.7 mil colors
Color Gamut 85 % (typical) ** 85 % (typical) ** 85 % (typical) **
** E2015HV/E2215HV/E2715H color gamut (typical) is based on CIE1976 (85 %)
and CIE1931 (72 %) test standards.
Resolution Specifications
Model number E2015HV
E2215HV/E2715H
Scan range
• Horizontal 30 kHz to 83 kHz (automatic)
• Vertical 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1600 x 900 at 60 Hz 1920 x 1080 at 60 Hz
Electrical Specifications
Model number E2015HV/E2215HV E2715H
Video input signals Analog RGB: 0.7 Volts
± 5 %, 75 ohm input
impedance
• Analog RGB: 0.7 Volts ± 5 %,
75 ohm input impedance
• Digital DVI-D TMDS, 600
mV for each dierential line,
positive polarity at 50 ohm
input impedance
• DisplayPort*, 600mV for
each dierential line, 100
ohm input impedance per
dierential pair
Synchronization input
signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on green)
AC input voltage /
frequency / current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A
(typical)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
*Supports DP 1.2 (CORE) specification. Excludes Fast AUX transaction, 3D
stereo transport , HBR Audio (or high data rate audio).
