Figure 1. Changing 2280 to 2230
3. To install the solid-state drive, see installing solid-state drive.
Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image indicates the location of the wireless card and provides a visual representation of the removal procedure.
Removing and installing Customer Replaceable Units (CRUs)
43
