Dell Inspiron 13 5000 User Manual

Replacing the power-adapter
port
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Procedure
1 Place the power-adapter port into the slot on the palm-rest assembly.
2 Align the screw hole on the power-adapter port with the screw hole on
the palm-rest assembly.
3 Replace the screw that secures the power-adapter port to the palm-rest
assembly.
4 Connect the power-adapter port-cable to the system board.
Post-requisites
1 Replace the display assembly.
2 Replace the wireless card.
3 Replace the battery.
4 Replace the base cover.
74

Dell Inspiron 13 5000 Specifications

General

Display Size	13.3 inches
Processor	Intel Core i5 or i7
RAM	Up to 16GB
Storage	Up to 1TB SSD
Display Resolution	1920 x 1080 (Full HD)
Operating System	Windows 10
Ports	1 x HDMI, 1 x SD card reader, 1 x headphone/microphone combo jack
Wireless	802.11ac Wi-Fi, Bluetooth 5.0
