Dell Inspiron 13 5000 User Manual

Removing the sensor board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the display assembly.
4 Follow the procedure from step 1 to step 3 in “Removing the display
panel”.
Procedure
CAUTION: Place the display-panel assembly on a soft and clean
surface to avoid scratching the display.
1 Remove the screw that secures the sensor board to the display panel.
2 Peel off the tape and open the latch to disconnect the sensor-board
cable from the sensor board.
97

Dell Inspiron 13 5000 Specifications

General

Display Size	13.3 inches
Processor	Intel Core i5 or i7
RAM	Up to 16GB
Storage	Up to 1TB SSD
Display Resolution	1920 x 1080 (Full HD)
Operating System	Windows 10
Ports	1 x HDMI, 1 x SD card reader, 1 x headphone/microphone combo jack
Wireless	802.11ac Wi-Fi, Bluetooth 5.0
