 Coin-Cell Battery
Dell™Inspiron™1300/B120/B130ServiceManual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
Removing the Coin-Cell Battery



1. Follow the instructions in Before Working Inside Your Computer.

2. Remove the hinge cover. See Removing the Hinge Cover.

3. Remove the keyboard. See Removing the Keyboard.

4. Locate the coin-cell battery and disconnect the cable from the system board connector by pulling toward the coin-cell battery.

5. Remove the cable from the guides and lift the coin-cell battery from the computer.
Replacing the Coin-Cell Battery

1. Connect the cable to the system board by pushing it into the connector.

2. Route the cable through the channel and press the coin-cell battery into place.
CAUTION: Before performing the following procedures, read the safety instructions in the Product Information Guide.
CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.

Dell Inspiron 1300 Specifications

General

Graphics	Intel GMA 900
Processor	Intel Celeron M or Intel Pentium M
RAM	256 MB to 2 GB
Storage	40 GB HDD
Display	15.4-inch WXGA (1280 x 800)
Optical Drive	DVD+/-RW
Operating System	Windows XP Home or Windows XP Professional
Weight	2.95 kg (6.5 lbs)
Battery	6-cell lithium-ion
Dimensions	10.5"
