 Memory, Optical Drive, and Mini PCI Card
Dell™Inspiron™1300/B120/B130ServiceManual
Memory
Optical Drive
Mini PCI Card
Memory

Removing the Memory Module



1. Follow the instructions in Before Working Inside Your Computer.

2. Ground yourself by touching one of the metal connectors on the back of the computer.

3. Turn the computer over, loosen the captive screws on the memory module/Mini PCI cover, and then remove the cover.

4. If you are replacing a memory module, remove the existing module:
a. Use your fingertips to carefully spread apart the securing clips on each end of the memory module connector until the module pops up.
b. Remove the module from the connector.
CAUTION: BeforeworkinginsideyourDell™computer,readthesafetyinstructionsintheProduct Information Guide.
CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
NOTE: Memory modules purchased from Dell are covered under your computer warranty.
NOTE: If you leave the area, ground yourself again when you return to the computer.


1
captive screws (3)


NOTICE: To prevent damage to the memory module connector, do not use tools to spread the memory-module securing clips.

Dell Inspiron 1300 Specifications

General

Graphics	Intel GMA 900
Processor	Intel Celeron M or Intel Pentium M
RAM	256 MB to 2 GB
Storage	40 GB HDD
Display	15.4-inch WXGA (1280 x 800)
Optical Drive	DVD+/-RW
Operating System	Windows XP Home or Windows XP Professional
Weight	2.95 kg (6.5 lbs)
Battery	6-cell lithium-ion
Dimensions	10.5"
