Dell Inspiron 1300 User Manual

Installing the Mini PCI Card

1. Install the replacement Mini PCI card:
a. Align the Mini PCI card with the connector at a 45-degree angle, and press the Mini PCI card into the connector until it clicks.
b. Connect the antenna cable to the Mini PCI card. Make sure the cable snaps onto the primary connector on the Mini PCI card.

2. Replace the memory module/Mini PCI cover and tighten the screws.

3. Insert the battery into the battery bay, or connect the AC adapter to your computer and an electrical outlet.

4. Turn on the computer.
Back to Contents Page

NOTICE: To avoid damaging the Mini PCI card, make sure the antenna cable is not under the card when you press the card into place.
1
Mini PCI card
2
metal securing tabs (2)




1
antenna cable


NOTICE: If the cover is difficult to close, remove the module and reinstall it. Forcing the cover to close may damage your computer.

Dell Inspiron 1300 Specifications

General

Graphics	Intel GMA 900
Processor	Intel Celeron M or Intel Pentium M
RAM	256 MB to 2 GB
Storage	40 GB HDD
Display	15.4-inch WXGA (1280 x 800)
Optical Drive	DVD+/-RW
Operating System	Windows XP Home or Windows XP Professional
Weight	2.95 kg (6.5 lbs)
Battery	6-cell lithium-ion
Dimensions	10.5"
