Antenna
Dell™Inspiron™1300/B120/B130ServiceManual
Replacing the Antenna
Replacing the Antenna
1. Follow the instructions in Before Working Inside Your Computer.
2. Remove the hard drive. See Removing the Hard Drive.
3. Remove the optical drive. See Removing the Optical Drive.
4. Remove the memory module. See Removing the Memory Module.
5. Remove the Mini PCI card. See Removing the Mini PCI Card.
6. Remove the microprocessor thermal-cooling assembly. See Removing the Microprocessor Thermal-Cooling Assembly.
7. Remove the microprocessor. See Removing the Microprocessor Module.
8. Remove the hinge cover. See Removing the Hinge Cover.
9. Remove the keyboard. See Removing the Keyboard.
10. Remove the display assembly. See Removing the Display Assembly.
11. Remove the palm rest. See Removing the Palm Rest.
12. Remove the modem. See Removing the Modem.
13. Remove the speakers connector. See Removing the Speakers.
14. Remove the system board. See Removing the System Board.
15. Remove the antenna cable from the guides.
16. Replace the antenna cable, securing it under the guides.
CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
