Dell Latitude 7400 User Manual

Installing the battery
1. Align and place the battery in the computer [1].
2. Tighten the two captive screws [2] to secure the battery (4-Cell) to the computer.
NOTE: A 3-Cell battery has single captive screw that secures the battery to the computer.
3. Connect the battery cable to its connector on the system board [3].
Removing and installing components
23

Dell Latitude 7400 Specifications

General

Processor	8th Generation Intel Core i5/i7
Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Pro
Display	14.0-inch FHD (1920 x 1080)
RAM	Up to 16GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Weight	1.36 kg (3.0lbs)
Ports	HDMI 1.4, microSD card reader
Wireless	Bluetooth 5.0
Webcam	720p HD camera with dual array microphones
