Installing the WWAN card

1. Place the WWAN card into its connector on the system board [1].

2. Connect the antennae cables to the connectors on WWAN card [2].

3. Place the metal bracket over the antennae connectors on the WWAN card [3].

4. Replace the single (M2x3) screw to secure the metal bracket to the WWAN card and the system board [4].

Removing and installing components
