Dell Latitude D430 User Manual

Specifications 155
Specifications
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer,
click Start→ Help and Support and select the option to view information about your computer.
Processor
Processor type Intel Core™ Solo and Intel Core 2 Duo
processors
L1 cache 32 KB (internal)
L2 cache 2 MB
External bus frequency 533
System Information
System chipset Intel 945 GMS
Data bus width 64 bits
DRAM bus width 64 bits
Processor address bus width 32 bits
PC Card/Express Card
CardBus controller Ricoh R5C843
PC Card connector
80-pin
Cards supported Type I and II cards
34mm New Card with adapter
PC Card connector size 68 pins
Data width (maximum) PCMCIA 16 bits
CardBus 32 bits
Memory
Memory module connector one user-accessible DIMM socket
Memory module capacities 1-GB minimum to 2 GB maximum
Memory type 533 MHz DDRII SDRAM (supports up to
667 MHz DDRII)

Dell Latitude D430 Specifications

General

RAM	Up to 2GB DDR2
Graphics	Intel GMA 950
Battery	4-cell or 6-cell Lithium Ion
Chipset	Intel 945GMS
Processor	Intel Core 2 Duo U7600 (1.2 GHz)
Storage	60GB, 80GB
Display	12.1-inch WXGA (1280x800) LCD
Operating System	Windows XP Professional
Optical Drive	External (optional)
Wireless	802.11a/b/g
Ports	2 x USB 2.0, VGA, Ethernet, Modem, Headphone/Microphone, Docking Connector
