4. Install:
a) palmrest
b) display assembly
c) keyboard
d) keyboard trim
e) bluetooth card
f) hard drive
g) base cover
h) battery
5. Follow the procedures in
After Working Inside Your Computer
.
Removing the Power-Connector Port
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove:
a) battery
b) base cover
3. Disconnect the power-connector cable from the system board.
4. Remove the screw that secures the power-connector bracket to the computer.
32
