5. Remove the power-connector bracket from the computer.
6. Remove the power-connector cable from the computer.
Installing the Power-Connector Port
1. Connect the power-connector cable to the computer.
2. Install the power-connector bracket to its position in the computer.
3. Tighten the screw to secure the power-connector bracket to the computer.
4. Connect the power-connector cable to the system board.
5. Install:
a) base cover
b) battery
6. Follow the procedures in
After Working Inside Your Computer
.
Removing the Power LED Board
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove:
a) battery
b) base cover
c) hard drive
d) bluetooth module
e) keyboard trim
f) keyboard
g) display assembly
h) display bezel
i) display panel
33
