Removing the solid-state drive/Intel Optane
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
Remove the base cover.
Procedure
1. Locate the solid-state drive/Intel Optane memory on the system board.
2. Remove the screw (M2x3) that secures the solid-state drive/Intel Optane memory to the keyboard shield.
3. Slide and remove the solid-state drive/Intel Optane memory from the solid-state drive/Intel Optane memory slot.
9
Removing the solid-state drive/Intel Optane 19
