Replacing the keyboard
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Place the keyboard membrane on the back of the keyboard.
2. Align the keyboard membrane with the folding line and fold the keyboard membrane.
3. Align the screw holes on the keyboard with the screw holes on the palm-rest assembly.
4. Replace the eight screws (M1.2x1.5) that secure the keyboard to the palm-rest assembly.
36
56 Replacing the keyboard
