Removing the battery
WARNING
: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in
Before working inside your computer. After working inside your computer, follow the instructions in After working inside
y
our computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/
r
egulatory_compliance.
Prerequisites
Remove the base cover
.
Procedure
1 Peel the tape that secures the battery cable to the system board.
2 Peel the tape that secures the battery cable connection to the system board.
3 Disconnect the battery cable from the system board.
4 Remove the four screws (M2x3) that secure the battery to the palm-rest and keyboard assembly.
5 Lift the battery o
î the palm-rest and keyboard assembly.
8
18 Removing the battery
