Removing the power button with ngerprin
t
reader
WARNING
: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in
Before working inside your computer. After working inside your computer, follow the instructions in After working inside
y
our computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/
r
egulatory_compliance.
NOTE
: Applicable only for computers that are shipped with ngerprint reader.
Prerequisites
1 Remove the base cover
.
2 Remove the fan
.
3 Remove the display assembly
.
4 Remove the I/O board.
Procedure
1 Remove the two screws (M2x3) that secure the power button with ngerprint reader to the palm-rest and keyboard assembly.
2 Peel the ngerprint-reader cable and the ngerprint-reader board from the palm-rest and keyboard assembly.
3 Lift the ngerprint-reader board o the palm-rest and keyboard assembly.
32
Removing the power button with ngerprint reader 55
