116 Installing System Components
Removing an iDRAC6 Express Card
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 78.
3
If installed, remove the expansion card from the expansion-card slot.
See "Removing an Expansion Card" on page 96.
4
Pull back slightly on the retention standoff tab at the front edge
of the card and gently lift the card off the retention standoff.
See Figure 3-17.
As the holder releases from the standoff, the connector under the card
disengages from the system board connector.
5
Angle the card so that the notch on the card slips through the clip on the
system board.
6
If applicable, replace the expansion card. See "Installing an Expansion
Card" on page 94.
7
Close the system. See "Closing the System" on page 79.
8
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
R310HOM.book Page 116 Thursday, March 4, 2010 1:03 AM
