Troubleshooting Your System 145
Troubleshooting Your System
Safety First—For You and Your System
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
Troubleshooting System Startup Failure
If your system halts during startup prior to video output, especially after
installing an operating system or reconfiguring your system’s hardware, check
for the following conditions:
• If you boot the system to the BIOS boot mode after installing an operating
system from the UEFI Boot Manager, the system will hang. The reverse is
also true. You must boot to the same boot mode in which you installed the
operating system. See "Using the System Setup Program and UEFI Boot
Manager" on page 53.
• Invalid memory configurations could cause the system to halt at startup
without any video output. See "System Memory" on page 106.
For all other startup issues, note the system messages that appear onscreen.
See "System Messages" on page 38 for more information.
Troubleshooting External Connections
Ensure that all external cables are securely attached to the external
connectors on your system before troubleshooting any external devices.
See Figure 1-1 and Figure 1-4 for the front-panel and back-panel connectors
on your system.
R310HOM.book Page 145 Thursday, March 4, 2010 1:03 AM
