78 Installing System Components
Opening and Closing the System
WARNING: Whenever you need to lift the system, get others to assist you. To
avoid injury, do not attempt to lift the system by yourself.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
Opening the System
1
Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet and peripherals.
2
Rotate the latch release lock counter clockwise to the unlocked position.
See Figure 3-3.
3
Grasp the cover on both sides while pressing your thumbs on the latch
release lock and the indent. Carefully slide the cover toward the back of
the system, and lift it away from the system. See Figure 3-3.
R310HOM.book Page 78 Thursday, March 4, 2010 1:03 AM
