20 PowerEdge R720 and R720xd Technical Guide
4 Processors
Dell PowerEdge R720 and R720xd servers feature the exceptional performance, value and power
efficiency of the Intel Xeon processor E5-2600 v2 product family. With up to 12 cores and 30MB
cache, E5-2600 v2 processors have the capacity to deliver performance gains of up to 40% over
previous-generation E5-2600 processors. No matter your constraint — floor space, power or
budget — E5-2600 v2 processors can help you achieve more computational horsepower, in the
same footprint, with better security and power efficiency.
Processor features
The Intel Xeon processor E5-2600 v2 product family has powerful new features and improves upon
many of the capabilities of the predecessor Intel Xeon processor E5-2600 series:
 With up to four additional cores, 10MB more cache and a 17% increase in memory speeds,
E5-2600 v2 processors may boost performance by up to 40% in PowerEdge server platforms
 Support for DDR3 1866MT/s memory provides faster connections throughout the system
 Up to 24 DIMM slots and support for up to 32GB DIMMs enable memory capacity of 768GB
Dell’s exclusive Fault Resilient Memory technology provides a protected memory zone for a
hypervisor without consuming half of the total RAM in the system,
 In combination with Fault Resilient Memory, E5-2600 v2 processors offer Failsafe Virtualization
for unsurpassed industry protection for virtual machines.
 Intel Secure Key and Intel OS Guard deliver faster and more secure encryption
 Advanced Programmable Interrupt Controller virtualization (APICv) improves virtualization
performance by reducing virtual machine (VM) exits, thereby reducing overhead required to
service every APIC interrupt
 Intel Integrated PCI Express 3.0 provides up to 40 lanes per socket
 Intel Turbo Boost Technology 2.0 delivers up to double the boost than the previous generation
turbo technology
 Intel Data Direct I/O (DDIO) allows I/O traffic to skip the main system memory and be directed
straight to the processor cache, which can provide a significant reduction in latency as well as
allowing memory to remain in a low-power state
 Intel Advanced Vector Extensions offer up to double the floating point operations per clock
cycle by doubling the length of registers, which can be useful in large-number calculations,
integral to many technical, financial and scientific computing problems.
For more information on Intel Xeon processor E5-2600 v2 product family, visit Intel.com.

Dell PowerEdge R720 Specifications

General

Tcase	77.4 °C
Bus type	QPI
Stepping	C2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620
System bus rate	7.2 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor threads	12
Processor codename	Sandy Bridge EP
Motherboard chipset	Intel C600
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	25
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	42.6 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
Optical drive type	DVD-RW
Total storage capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
Number of HDDs supported	8
Memory slots	24x DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	4
PCI Express slots version	3.0
Power supply	750 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (2U)
Processor ARK ID	64594
Intel® Turbo Boost Technology	1.0
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
