24 PowerEdge R720 and R720xd Technical Guide
5 Memory
More memory options are available than ever before with the Dell PowerEdge R720 and R720xd—
greater capacities, higher frequencies, and more flexibility. The R720 and R720xd support up to
768GB of memory (24 DIMMs) and speeds up to 1866MT/s, providing high performance in a variety
of applications. High memory density means there is no compromise when it comes to virtualization.
Increase your uptime and reduce data loss due to Dell’s focus on reliability, availability, and
serviceability (RAS) features. RAS aids in the rapid and accurate diagnosis of faults which require
service, increasing your memory reliability. System uptime is reinforced with RAS features like
memory mirroring, sparing, and many others.
In addition to supporting existing unbuffered DIMMs (UDIMMs) and registered DIMMs (RDIMMs), the
R720 and R720xd support load reduced DIMMs (LRDIMMs), which use a buffer to reduce memory
loading and provide greater density, allowing for the maximum platform memory capacity.
Supported memory
Table 7 lists the memory technologies supported by the R720 and R720xd.
Table 7. Memory technologies supported
Feature
UDIMM
RDIMM
LRDIMM
Register
No
Yes
Yes
Buffer
No
No
Yes
Frequencies*
1600MT/s
1333, 1600 or 1866MT/s
1600 or 1866MT/s
Ranks supported
1
1, 2 or 4
4
Capacity per DIMM
4GB
4, 8, 16 or 32GB
32GB
Maximum DIMMs per
channel
2
3
3
DRAM technology
x8
x4 or x8
x4
Temperature sensor
Yes
Yes
Yes
Error Correction Code
(ECC)
Yes
Yes
Yes
Single Device Disable
Code (SDDC)
Yes (with advanced
ECC mode)
Yes
Yes
Address parity
Yes
Yes
Yes
*Although the R720 and R720xd support DIMM speeds lower than 1600MT/s, you can only purchase these systems
with DIMM speeds of 1600MT/s and 1866MT/s on Dell.com/PowerEdge.

Dell PowerEdge R720 Specifications

General

Tcase	77.4 °C
Bus type	QPI
Stepping	C2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620
System bus rate	7.2 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor threads	12
Processor codename	Sandy Bridge EP
Motherboard chipset	Intel C600
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	25
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	42.6 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
Optical drive type	DVD-RW
Total storage capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
Number of HDDs supported	8
Memory slots	24x DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	4
PCI Express slots version	3.0
Power supply	750 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (2U)
Processor ARK ID	64594
Intel® Turbo Boost Technology	1.0
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
