Table 14 lists the RAID controllers supported on the R720 and R720xd.
Table 14. RAID controllers
Controller
Description
Features
RAID
modes
Form factor
Usage model
PERC
H810
External
Eight-port, external,
6Gb/s PCIe RAID
controller that supports
up to 192 SATA and SAS
HDDs or SSDs
Includes 1GB NV DDR3
cache, premium
performance and feature
set, security SED/EKMS,
and SSD as cache
0, 1, 10, 5,
50, 6, 60
Adapter
Premium
performance
PERC
H710P
Internal
Eight-port, internal,
6Gb/s PCIe RAID
controller that supports
up to 32 SATA and SAS
HDDs or SSDs
Includes 1GB NV DDR3
cache, premium
performance and feature
set, security SED/EKMS,
and SSD as cache
0, 1, 10, 5,
50, 6, 60
Adapter
Premium
performance
PERC H710
Eight-port, internal,
6Gb/s PCIe RAID
controller that supports
up to 32 SATA and SAS
HDDs or SSDs
Includes 512MB DDR3
cache, advanced feature
set, security SED/EKMS
0, 1, 10, 5,
50, 6, 60
Adapter
Performance
PERC
H310
Eight-port, internal,
6Gb/s PCIe RAID
controller that is a
low-cost, entry-level
solution supporting up
to 32 SATA and SAS
HDDs or SSDs
Supports hot-plug drives,
expansion, pass-through
0, 1, 10, 5,
50
Adapter
Value
PERC S110
Software
RAID
(R720 only)
3Gb/s SATA software
RAID controller that is a
low-cost, entry-level
solution, supporting up
to 4 physical disks or
eight virtual disks
Supports up to 4
hot-plug SATA drives, no
expansion, Microsoft
Windows only
0, 1, 5, 10
System
board-
embedded
SATA
Entry-level
For more information about the latest PERC offerings, see Dell.com/PERC.
CacheCade
CacheCade is a technology that provides automated storage tiering on SSDs with the PERC H810
and H710P. It works by detecting the most-often accessed data and copying it over time to the
CacheCade SSD(s) where that cached data is accessed directly, instead of accessing the hard disk
drives. This can dramatically increase how your applications respond when they are under peak
traffic times and how they perform when response time is critical.
CacheCade provides cost-effective performance scaling for database-type applications that
perform lots of random reads, and saves the cost of adding extra drives.

Dell PowerEdge R720 Specifications

General

Tcase	77.4 °C
Bus type	QPI
Stepping	C2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620
System bus rate	7.2 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor threads	12
Processor codename	Sandy Bridge EP
Motherboard chipset	Intel C600
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	25
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	42.6 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
Optical drive type	DVD-RW
Total storage capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
Number of HDDs supported	8
Memory slots	24x DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	4
PCI Express slots version	3.0
Power supply	750 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (2U)
Processor ARK ID	64594
Intel® Turbo Boost Technology	1.0
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
