35 PowerEdge R720 and R720xd Technical Guide
 Automation of firmware and driver version deployment upon component replacement
 Automatic monitoring of NIC status and notification on SNMP traps
 Local or remote reconfiguration of any NIC, physical or virtual
 PXE boot enabled on all LOM and NDCs for ease of use
 Boot from SAN (iSCSI, FCoE) configuration for networking devices through the Lifecycle
Controller GUI
PCIe expansion
For information on card installation, requirements, and slot priorities, see the PowerEdge R720 and
R720xd Owner’s Manual on Dell.com/Support/Manuals.
PCIe slots
The R720 and R720xd provide greatly expanded PCIe slot capability over their predecessor servers.
This is made possible by the 40 PCIe lanes available from each processor in the system. Two
processors are required in the system to enable all PCIe slots. The R720 and R720xd have been
designed to be PCIe 3.0 compliant in order to take full advantage of the processor capabilities. Table
16 details the R720 and R720xd PCIe slots.
Table 16. PCIe expansion slots
System
R720
R720xd
Slots
1
7
6
Slot types
One x16 full-length, full-height
Three x8 full-length, full-height
Three x8 half-length, half-height
Two x16 full-length, full-height
One x8 full-length, full-height
Three x8 half-length, half-height
1
In a single-processor configuration, slots 1–4 are not usable.
PCIe expansion cards
The R720 and R720xd support a variety of PCIe expansion cards. Table 17 lists the supported add-in
NICs and HBAs for the R720 and R720xd.
Table 17. Supported NICs and HBAs
Type
Adapter
1Gb/10Gb NICs
Broadcom 5720 2x1Gb Base-T
Broadcom 5719 4x1Gb Base-T
Intel I350 2x1Gb Base-T
Intel I350 4x1Gb Base-T
Broadcom 57810S 2x10Gb SFP+
Broadcom 57810S 2x10Gb Base-T
Intel X520 2x10Gb SFP+

Dell PowerEdge R720 Specifications

General

Tcase	77.4 °C
Bus type	QPI
Stepping	C2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620
System bus rate	7.2 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor threads	12
Processor codename	Sandy Bridge EP
Motherboard chipset	Intel C600
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	25
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	42.6 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
Optical drive type	DVD-RW
Total storage capacity	- GB
Maximum storage capacity	32 TB
Number of HDDs installed	-
Number of HDDs supported	8
Memory slots	24x DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	4
PCI Express slots version	3.0
Power supply	750 W
Compatible operating systems	Microsoft Windows Server 2012 \\r Microsoft Windows Server 2012 Essentials\\r Microsoft Windows Server 2008 R2 \\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Chassis type	Rack (2U)
Processor ARK ID	64594
Intel® Turbo Boost Technology	1.0
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Width	- mm
