Installing System Components 79
3 Open the system. See "Opening the System" on page 57.
4 Remove the expansion card stabilizer. See "Removing the Expansion Card
Stabilizer" on page 72.
5 Open the expansion-card latch and remove the filler bracket. See
Figure 3-13.
NOTE: Keep this bracket in case you need to remove the expansion card.
Filler brackets must be installed over empty expansion-card slots to maintain
FCC certification of the system. The brackets also keep dust and dirt out of the
system and aid in proper cooling and airflow inside the system.
6 Holding the card by its edges, position the card so that the card-edge
connector aligns with the expansion-card connector on the expansion-card
riser.
7 Insert the card-edge connector firmly into the expansion-card connector
until the card is fully seated.
8 Close the expansion-card latch. See Figure 3-13.
9 Connect all cables to the expansion card.
10 Replace the expansion card stabilizer. See "Installing the Expansion Card
Stabilizer" on page 72.
11 Close the system. See "Closing the System" on page 58.
SAS Controller Expansion Card
Read the installation instructions in the documentation for your SAS
controller card. Install the card in the expansion card connector (see
"Installing an Expansion Card" on page 78), and connect the hard-drive
activity indicator cable from the card to the HD_ACT_CARD (AUXLED1)
connector on the system board (see Figure 6-1 for the connector location).
Secure the cables to the slots to manage the slack.
See "Hard Drives" on page 68 for information about connecting hard drives.
Mayzie_HOM.book Page 79 Monday, August 31, 2009 9:33 PM

Dell PowerEdge T110 Specifications

General

Tcase	72.7 °C
Bus type	DMI
Stepping	B1
FSB Parity	No
Processor code	SLBLD
Processor cache	8 MB
Processor cores	4
Processor model	X3450
System bus rate	2.5 GT/s
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor threads	8
Processor codename	Lynnfield
Processing Die size	296 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 4x4
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	800, 1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
Hot-swap	-
HDD capacity	500 GB
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	1000 GB
Maximum storage capacity	- TB
Number of HDDs installed	2
Internal memory	4 GB
Memory clock speed	1066 MHz
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
Graphics card	G200eW
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	2.0
Power supply	305 W
Compatible operating systems	Microsoft SQL Server 2008 R2, Microsoft Windows Small Business Server 2008, Microsoft Windows Essential Business Server 2008, Microsoft Windows Server 2008 Foundation R2, Microsoft Windows Server 2008 SP2, x86/x64 (x64 Hyper-VTM), Microsoft Windows Server 2008 R2, x64 (Hyper-VTM v2), Microsoft Windows HPC Server 2008, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux
Chassis type	Tower
Processor ARK ID	42929
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	463.8 mm
Width	188.64 mm
Height	418.55 mm
