Specifications 127
15
Specifications
Processor
Processor type Intel
®
Core 2™ Duo and Core 2 Extreme
processors
L1 cache 64 KB (internal)
L2 cache Intel Core 2 Duo: 4 MB (on die)
Intel Core Extreme: 4 MB (on die)
External bus frequency 800 MHz
System Information
System chipset Intel 965PM
Data bus width 64 bits
DRAM bus width 64 bits
Processor address bus width 36 bits
Graphics bus internal
PC Card
CardBus controller OZ711
PC Card connector one (supports one Type I or Type II card)
Cards supported 3.3 V and 5 V
PC Card connector size 80 pins
Data width (maximum) PCMCIA 16 bits
CardBus 32 bits
Smart Card
Read/write capabilities reads and writes to all ISO 7816 1/2/3/4
microprocessor cards (T=0, T=1)
Cards supported 3 V and 5 V
Program technology supported Java cards
Interface speed 9600–115,200 BPS
