Dell Precision Mobile Workstation M4800 User Manual

Installing the Base Cover
1. Slide in and place the base cover to align with the screw holes correctly on the computer.
2. Tighten the screws to secure the base cover to the computer.
3. Install the battery.
4. Follow the procedures in After Working Inside Your Computer.
Removing the Primary Memory
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the:
a. battery
b. base cover
3. Pry the retention clips away from the memory until it pops up. Lift the memory and remove it from
the computer.
Installing the Primary Memory
1. Insert the memory into the memory socket.
2. Press down the memory to secure the memory to the system board.
3. Install the:
a. base cover
b. battery
4. Follow the procedures in After Working Inside Your Computer.
Removing the Secondary Memory
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the:
a. battery
b. keyboard trim
c. keyboard
NOTE: The secondary memory is located below the keyboard.
3. Pry the retention clips away from the memory module until it pops up. Lift up the memory module
and remove it from the computer.
20

Dell Precision Mobile Workstation M4800 Specifications

General

Screen Size	15.6 inches
Graphics	NVIDIA Quadro K2100M
Display	15.6" FHD (1920x1080)
Memory	Up to 32GB DDR3L at 1600MHz
Storage	Up to 512GB SSD
Operating System	Windows 7 Professional, Windows 8.1 Pro
Weight	Starting at 2.88 kg
CPU	Intel Core i7-4800MQ (2.7GHz, up to 3.7GHz, 6MB cache)
GPU	NVIDIA Quadro K1100M, K2100M; AMD FirePro M5100
Ports	4 x USB 3.0, HDMI, VGA, RJ-45, headphone/microphone combo
Wireless	Intel Dual Band Wireless-AC 7260, Bluetooth 4.0
Battery	9-cell (97Whr) lithium-ion
Security	Smart card reader, fingerprint reader
Optical Drive	DVD-ROM, DVD+/-RW
Processor	4th Generation Intel Core i5 and Core i7 Processor Options
