b. hard drive
c. optical drive
d. keyboard
e. keyboard trim
f. base cover
g. battery
8. Follow the procedures in After Working Inside Your Computer.
Removing the Hinge Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the:
a. battery
b. base cover
c. keyboard trim
d. keyboard
e. optical drive
f. hard drive
g. palmrest
h. display assembly
3. Remove the screws that secure the hinge cover to the computer. Remove the hinge cover from the
computer.
Installing the Hinge Cover
1. Place the hinge cover in its position on the computer.
2. Tighten the screws to secure the hinge cover to the computer.
3. Install the:
a. display assembly
b. palmrest
c. hard drive
d. optical drive
e. keyboard
f. keyboard trim
44
