Dell S3422DW User Manual

12 │ About your monitor
Side view
Bottom view
7 952 1043 8
6
1
Bottom view without monitor stand
Label Description Use
1 Security-lock slot Secure your monitor using a security lock (purchased
separately) to prevent unauthorized movement of your
monitor.
2 Power connector Connect the power cable (shipped with your monitor).
3 HDMI 1 2.0 port Connect to your computer using a HDMI cable.
4 HDMI 2 2.0 port Connect to your computer using a HDMI cable.
5 Stand lock
feature
Lock the stand to the monitor using a M3 x 6 mm
screw (screw not included).
6 DP 1.2 port Connect to your computer using a DP cable.
7 Audio line out
port
Connect to an external speaker or a sub-woofer
(purchased separately).*
8 USB 3.0
upstream port
Connect the USB cable from this port to your
computer to enable the USB ports on your monitor.

Dell S3422DW Specifications

General

Panel type	VA
Color gamut	89.2 %
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	48 - 100 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480i, 480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	99.7 %
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Display brightness (typical)	300 cd/m²
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	2.2
Headphone out	-
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	92 W
Power consumption (off)	0.3 W
Power consumption (typical)	32 W
Package depth	949.96 mm
Package width	468.12 mm
Package height	225.04 mm
Package weight	14950 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Product color	Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	10 W
Cables included	AC, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	210 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9800 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.01 mm
Height (without stand)	364.5 mm
Weight (without stand)	6700 g
