Dell S3422DW User Manual

60 │ Troubleshooting
Product-specific problems
Specific
Symptoms
Possible Solutions
Screen image is too
small
∞
Check the Aspect Ratio setting in the Display settings
OSD.
∞
Reset the monitor to Factory Settings (Factory Reset).
Cannot adjust the
monitor with the
buttons on the
bottom of the panel
∞
Turn Off the monitor, unplug the power cord, plug it back,
and then turn On the monitor.
∞
Check if the OSD menu is locked. If yes, press and hold
the menu button for 6 seconds to unlock.
No Input Signal
when user controls
are pressed
∞
Check the signal source. Ensure the computer is not in
standby or sleep mode by moving the mouse or pressing
any key on the keyboard.
∞
Check if the video cable is plugged in properly. Disconnect
and reconnect the video cable if necessary.
∞
Reset the computer or video player.
The picture does
not fill the entire
screen
∞
Due to different video formats (aspect ratio) of DVDs, the
monitor may display in full screen.
∞
Run the built-in diagnostics.

Dell S3422DW Specifications

General

Panel type	VA
Color gamut	89.2 %
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	48 - 100 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480i, 480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	99.7 %
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Display brightness (typical)	300 cd/m²
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	2.2
Headphone out	-
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	92 W
Power consumption (off)	0.3 W
Power consumption (typical)	32 W
Package depth	949.96 mm
Package width	468.12 mm
Package height	225.04 mm
Package weight	14950 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Product color	Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	10 W
Cables included	AC, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	210 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9800 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.01 mm
Height (without stand)	364.5 mm
Weight (without stand)	6700 g
