Dell S3422DW User Manual

32 │ Operating your monitor
Control buttons
The following table describes the control buttons:
Control Buttons Description
1
Shortcut key/Preset
Modes
Use this button for choose from a list of preset
modes.
2
Shortcut key/Input
Source
Use the buttons to adjust the volume. Minimum is ‘0’
(-). Maximum is ‘100’ (+).
3
Menu
Use the Menu button at launch your on-screen
display (OSD) and select the OSD menu. See
Accessing the OSD menu.
4
Exit
Use this button to go back to the main menu or exit
the OSD main menu.
5
Power On/Off button
(with LED indicator)
Use the power button to turn the monitor on and
off.
Solid white light indicates the monitor is turned on.
Blinking white light indicates it is in Standby mode.

Dell S3422DW Specifications

General

Panel type	VA
Color gamut	89.2 %
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	48 - 100 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480i, 480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	99.7 %
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Display brightness (typical)	300 cd/m²
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	2.2
Headphone out	-
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	92 W
Power consumption (off)	0.3 W
Power consumption (typical)	32 W
Package depth	949.96 mm
Package width	468.12 mm
Package height	225.04 mm
Package weight	14950 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Product color	Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	10 W
Cables included	AC, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	210 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9800 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.01 mm
Height (without stand)	364.5 mm
Weight (without stand)	6700 g
