1
Display – Your display can vary based on
selections you made when purchasing
your computer. For more information about
displays, see the Dell Technology Guide.
2
Left digital array microphone – Combines
with the right digital array microphone
to provide high quality sound for video
chatting and voice recording.
3
Camera activity light – Turns on when the
camera is on.
4
Camera – Built-in camera for video
capture, conferencing, and chat.
FastAccess Facial Recognition – Helps
to keep your Dell
™
computer secure.
This facial recognition software learns
and recognizes your face each time you
login to your computer and minimizes the
need to manually login using passwords.
For more information, click Start
→
Programs→ FastAccess.
5
Right digital array microphone – Combines
with the left digital array microphone
to provide high quality sound for video
chatting and voice recording.
2
VGA connector – Connects to a
monitor or projector.
3
TV In connector – Connects to a TV to
view programs using the TV Tuner card
(optional, availability varies according to
regions).
4
Network connector – If you are
using a cabled network signal, this
connects your computer to a network or
broadband device.
5
DisplayPort connector – Digital
interface standard connector that
supports external DisplayPort monitors
and projectors.
6
HDMI connector – Connects to a TV
for both audio and video signals.
NOTE: For a monitor, only the video
signal will be read.
7
USB connectors (2) – Connect USB
devices, such as a mouse, keyboard,
printer, external drive, or MP3 player.
8
Audio In/ Microphone connector –
Connect to a microphone or input signal
for use with audio programs.
9
Audio Out/ Headphone connectors (2)
– Connect one or two pairs of headphones,
or send audio to a powered speaker or
sound system. The audio signal is the
same for both connectors.
