Dell W19B001 User Manual

Replacing the system-board
shield
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the slots on the system-board shield with the ports on the system board
and place the system-board shield on the display-assembly base.
2 Align the screw holes on the system-board shield with the screw holes on the
display-assembly base.
3 Replace the ve screws (M3x5) that secure the system-board shield to the
display-assembly base.
NOTE: Ensure that no cable is pinched by the system-board shield.
Post-requisites
1 Replace the back cover.
2 Replace the stand.
27
