Removing the media-card reader
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the stand.
2 Remove the back cover.
3 Remove the system-board shield.
Procedure
1 Open the latch, and disconnect the media-card reader cable from the system
board.
2 Peel oî the media-card reader cable from the display-assembly base and slide it
through the microphone cable and speaker cable.
3 Remove the screw (M3x5) that secures the media-card reader shield to the
display-assembly base.
4 Lift the media-card reader shield from the display-assembly base.
5 Remove the screw (M3x5) that secures the media-card reader board to the
display-assembly base.
39
