Replacing the camera
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Place the camera and camera bracket in the slot on the retractable-camera
assembly and snap it in place.
2 Align the screw holes on the camera-assembly cover with the screw holes on the
retractable-camera assembly.
3 Replace the three screws (M3x5) that secure the camera-assembly cover to the
retractable-camera assembly.
4 Press the top of the retractable-camera assembly to retract the retractable
camera.
5 Route the camera cable through the routing guides on the display-assembly
base.
6 Place the retractable-camera assembly on the display-panel base.
7 Replace the two screws (M3x5) that secure the retractable-camera assembly to
the display-assembly base.
8 Connect the camera cable to the system board.
Post-requisites
1 Replace the system-board shield.
2 Replace the back cover.
3 Replace the stand.
51
