122 Removing and Installing Parts
6
Slide the Media Card Reader into the drive bay until it clicks into place.
7
Attach the power and data cables to the back of the Media Card Reader.
1 media card reader 2 shoulder screws (4)
1 drive release latch 2 media card reader
1
2
1
2
