Delta ASD-A2 Series User Manual

Chapter 11 Specifications ASDA-A2
Revision February, 2017 11-17
11.2.2 ECMA 400V Series
Low Inertia Series
ECMA Series
J△06
J△08
J△09
J△10
J△13
04
07
07
10
10
20
30
Rated power (kW)
0.4
0.75
0.75
1
1.0
2.0
3.0
Rated torque (N-m)
*1
1.27
2.39
2.39
3.18
3.18
6.37
9.55
Max. torque (N-m)
3.82
7.16
7.14
8.78
9.54
19.1
28.65
Rated speed (r/min)
3000
3000
3000
3000
Maximum speed (r/min)
5000
3000
5000
4500
Rated current (A)
1.62
3.07
2.16
2.4
4.15
7.09
9.8
Max. instantaneous current
(A)
4.85
9.5
6.37
7.17
12.46
21.28
29.99
Power rating (kW/s)
58.2
50.4
29.6
38.6
38.2
91.2
71.8
Rotor inertia
(× 10
-4
kg.m
2
)
0.277
1.13
1.93
2.62
2.65
4.45
12.7
Mechanical constant (ms)
0.47
0.66
1.56
1.06
0.77
0.58
0.99
Torque constant-KT (N-m/A)
0.79
0.78
1.12
1.29
0.77
0.9
0.97
Voltage constant-KE
(mV/(r/min))
30.6
28.24
42
50.9
29.0
34.4
37.3
Armature resistance (Ohm)
3.95
1.22
3.62
2.58
0.617
0.388
0.269
Armature inductance (mH)
21.3
10.68
21.2
15.28
6.03
4.62
3.55
Electric constant (ms)
5.39
8.75
5.85
5.93
9.77
11.9
13.2
Insulation class
Class A (UL), Class B (CE)
Insulation resistance
>100 M, DC 500 V
Insulation strength
2.3k Vac, 1 sec
Weight (kg)
(without brake)
1.6
3.0
2.9
3.8
4.3
6.2
7.8
Weight (kg) (with brake)
2.0
3.8
-
-
4.7
7.2
9.2
Radial max. loading (N)
19.6
245
245
245
490
490
490
Axial max. loading (N)
68
98
98
98
98
98
98
Power rating (kW/s)
(with brake)
53.8
48.4
29.3
37.9
30.4
82
65.1
Rotor inertia
(× 10
-4
kg.m
2
) (with brake)
0.3
1.18
1.95
2.67
3.33
4.95
14.0
Mechanical constant (ms)
(with brake)
0.52
0.65
1.57
1.08
0.96
0.65
1.09
Brake holding torque
[Nt-m (min)]
*2
1.3
2.5
2.5
2.5
8
8
10.0
Brake power consumption
(at 20
o
C) [W]
6.5
8.5
8.2
8.2
18.5
18.5
19.0
