Delta ASDA-A2 Series User Manual

Chapter 1 Inspection and Model Explanation ASDA-A2
Revision February, 2017 1-7
1. The boxes () at the ends of the servo drive model names are for optional configurations. For the actual
model name, please refer to the ordering information of the actual purchased product.
2. The boxes (
△
) in the model names are for encoder resolution types. △= 1: Incremental type, 20-bit; △=
2: Incremental type, 17-bit;
△= 3: 2500 ppr; △= A: Absolute type). The listed motor model name is for
information searching, please contact to your local distributors for actual purchased product.
3. The boxes () in the model names represents brake or keyway oil seal.
4 *11kw and 15kW will be available soon.
The above table shows the specification of servo drive which has triple rated current. For detailed
specification of the servo motor and servo drive, please refer to Chapter 11.
NOTE
Motor Servo Drive
Motor
series
Power
Output
(W)
Model Number
Rated
Current
(Arms)
Max.
Instantaneous
current
(A)
Model Number
Continuou
s Output
Current
(Arms)
Max.
Instanta
neous
output
current
(A)
High Inertia
ECMA-C/G 3000 r/min
Single-
/Three-
phase
400
ECMA-C△0604□H
2.60 7.80
ASD-A2-0421-□ 2.60 7.80
750
ECMA-C△0807□H
5.10 15.30
ASD-A2-0721-□ 5.10 15.30
300
ECMA-G△1303□S
2.50 7.50 ASD-A2-0421-□ 2.60 7.80
600
ECMA-G△1306□S
4.80 14.40
ASD-A2-0721-□ 5.10 15.30
900
ECMA-G△1309□S
7.50 22.50
ASD-A2-1021-□ 7.30 21.90
