Chapter 1 Introduction
VFD-EL-W
1-3
1.1.4 Drive Frames and Appearances
Frame A1
Frame A2
input terminals
R/L1, S/L2, T/L3
frequency control knob
digital keypad
control board cover
grounding terminal
output terminals
U/T1, V/T2, W/T3
digital keypad
choose NPN/PNP
choose ACI/AVI
control terminals
RS485 terminal
(RJ45)
input terminals
(R/L1, S/L2, T/L3)
frequency control knob
digital keypad
control board cover
output terminals
(U/T1, V/T2, W/T3)
grounding terminal
digital keypad
choose NPN/ PNP
choose ACI/ AVI
control terminals
RS485 terminal
(RJ45)
