Chapter 1 Introduction
VFD-EL-W
1-4
Frame B
input terminals
(R/L1, S/L2, T/L3)
frequency
control knob
digital keypad
case
control board
cover
output terminals
(U/T1, V/T2, W/T3)
grounding terminal
digital keypad
choose NPN/ PNP
choose AVI/ ACI
control terminals
RS485 terminal
(RJ45)
