Chapter 11 Summary of Parameter SettingsME300
11-16
Pr. Explanation Settings Default
6: Power factor
7: Power
9: AVI
12: Iq current command
13: Iq feedback value
14: Id current command
15: Id feedback value
16: Vq-axis voltage command
17: Vd-axis voltage command
21: RS-485 analog output
23: Constant voltage output
03-21 Analog output gain (AFM) 0.0–500.0% 100.0
03-22
Analog output in REV
direction (AFM)
0: Absolute value of output voltage
1: Reverse output 0 V; forward output 0
–10 V
2: Reverse output 5
–0 V; forward output 5–10 V
0
03-27 AFM output bias
-100.00
–100.00%
0.00
03-28
AVI terminal input
selection
0: 0–10 V
1: 0-20 mA (Pr.03-57–03-62 is valid)
2: 4-20 mA (Pr.03-57–03-62 is valid)
0
03-32
AFM DC output setting
level
0.00–100.00% 0.00
03-35 AFM filter output time 0.00–20.00 sec. 0.01
03-39 VR input selection
0: Disable
1: Frequency command
1
03-40 VR Input Bias -100.0–100.0% 0.0
03-41
VR Positive / Negative
Bias
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving as
the center
4: Bias serves as the center
0
03-42 VR Gain -500.0–500.0% 100.0
03-43 VR Filter Time 0–2.00 sec. 0.01
03-44
Multi-function MO output
by AI level source
0: AVI
1: ACI
0
03-45 AI upper level 1
-100.00
–100.00%
50.00
03-46 AI lower level 2
-100.00
–100.00%
10.00
03-50
Analog input curve
selection
0: Regular curve
1: Three-point curve of AVI (& AI10)
2: Three-point curve of ACI (& AI11)
0
