Chapter 12 Description of Parameter SettingsME300
12.1-06-11
Fault Code
bit 0 bit 1 bit 2 bit 3 bit 4 bit 5 bit 6
current Volt. OL SYS FBK EXI CE
0: No fault record
1: Over-current during acceleration (ocA)
●
2: Over-current during deceleration (ocd)
●
3: Over-current during constant speed (ocn)
●
4: Ground fault (GFF)
●
6: Over-current at stop (ocS)
●
7: Over-voltage during acceleration (ovA)
●
8: Over-voltage during deceleration (ovd)
●
9: Over-voltage during constant speed (ovn)
●
10: Over-voltage at stop (ovS)
●
11: Low-voltage during acceleration (LvA)
●
12: Low-voltage during deceleration (Lvd)
●
13: Low-voltage during constant speed (Lvn)
●
14: Low-voltage at stop (LvS)
●
15: Phase loss protection (orP)
●
16: IGBT over-heat (oH1)
●
18: TH1 open: IGBT over-heat protection error (tH1o)
●
21: Drive over-load (oL)
●
22: Electronic thermal relay protection 1 (EoL1)
●
23: Electronic thermal relay protection 2 (EoL2)
●
24: Motor PTC over-heat (oH3)
●
26: Over-torque 1 (ot1)
●
27: Over-torque 2 (ot2)
●
28: Low current (uC)
●
31: Memory read-out error (cF2)
●
33: U-phase current detection error (cd1)
●
34: V-phase current detection error (cd2)
●
35: W-phase current detection error (cd3)
●
36: Clamp current detection error (Hd0)
●
37: Over-current detection error (Hd1)
●
40: Auto-tuning error (AUE)
●
41: PID feedback loss (AFE)
●
48: Analog current input loss (ACE)
●
49: External fault input (EF)
●
50: Emergency stop (EF1)
●
51: External Base Block (B.B.)
●
52: Password error (Pcod)
●
54: Communication error (CE1)
●
55: Communication error (CE2)
●
