Surround
This unit is equipped with a digital signal processing circuit that lets you play program sources in the surround mode to achieve the same sense of presence as in a movie theater.
Surround modes and surround parameters
This table shows the speakers that can be used in each surround mode and the surround parameters adjustable in each surround mode.
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set.
D This indicates the audio output channels. The output channels depend on the settings of C page 5 “Speaker Config.”.
Surround mode (vpage18)
Channel output
Audio Adjust (vpage34)
Front L/R Center Surround L/R Subwoofer
Mode
(vpage34)
LFE z4
(vpage34)
D. Comp z2
(vpage35)
DRC z3
(vpage35)
DIRECT (2 channel)
S D
z1
S S
DIRECT (Multi-channel)
S D D D S S S
STEREO
S D S S S
MULTI CH IN
S D D D S
DOLBY PRO LOGIC g S D D D S S S
DTS NEO:6
S D D D S S S
DOLBY DIGITAL
S D D D S S
DOLBY DIGITAL Plus
S D D D S S
DOLBY TrueHD
S D D D S
DTS SURROUND
S D D D S S
DTS 96/24
S D D D S S
DTS-HD
S D D D S S
DTS Express
S D D D S S
MULTI CH STEREO
S D D D S S
VIRTUAL
S D
z1
S S
z1 Only when “SW Mode” is set to “LFE+Main” (C page 6 “Bass Setting”), sound is output from the subwoofer.
z2 This item can be selected when a Dolby Digital or DTS signal is played.
z3 This item can be selected when a Dolby TrueHD signal is played.
z4 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.
Basic version
Advanced version
InformationInformation

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
