Denon AVR-1713 Service Manual

111
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement
parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
C1 nsp FRONT PCB ASS'Y 1613E3, 1713E3 COP12423D 1 *
C1 nsp FRONT PCB ASS'Y 1713E2 COP12423G 1 *
C1 nsp FRONT PCB ASS'Y 1713E1C, 1723E1C COP12423E 1 *
C1-1 - FRONT PCB
C1-2 - POWER KNOB PCB
C1-3 - HEADPHONE PCB
C1-4 - USB PCB
C1-5 - MIC PCB
C1-6 - FOR HDMI FFC CABLE PCB
C2 nsp MAIN PCB ASS'Y 1613E3, 1713E3 COP12425E 1 *
C2 nsp MAIN PCB ASS'Y 1713E2 COP12425F 1 *
C2 nsp MAIN PCB ASS'Y 1713E1C, 1723E1C COP12425G 1 *
C2-1 - MAIN PCB
C2-2 - CABLE PCB
C2-3 - HDMI CABLE PCB
C2-4 - CARD CABLE FIX PCB
C2-5 - TUNER PCB
C3 8U6391000600D DIGITAL PCB ASS'Y 1613E3 COP12428B 1 *
C3 8U6391000610D DIGITAL PCB ASS'Y
1713E3 COP12428C 1 *
C3 8U6391000620D DIGITAL PCB ASS'Y 1713E2 COP12428D 1 *
C3 8U6391000630D DIGITAL PCB ASS'Y
1713E1C COP12428E 1 *
C3 8U6391000640D DIGITAL PCB ASS'Y
1723E1C COP12428G 1 *
C3-1 - DIGITAL PCB
C3-2 - F-HDMI PCB
C4 nsp POWER PCB ASS'Y
1613E3, 1713E3 COP12427B 1 *
C4 nsp POWER PCB ASS'Y
1713E2 COP12427C 1 *
C4 nsp POWER PCB ASS'Y
1713E1C, 1723E1C COP12427D 1 *
C4-1 - SMPS PCB
C4-2 - REGULATOR PCB
z
C6 943101101320D TRANS,POWER AVR1613/1713/E3,(85.8X63) 1613E3, 1713E3 CLT5U052ZU 1 *
z
C6 943101101330D TRANS,POWER AVR1713/E2,(85.8X63) 1713E2 CLT5U052ZE 1 *
z
C6 943101101340D TRANS,POWER AVR1713/1723/E1C,(85.8X63) 1713E1C, 1723E1C CLT5U052ZH 1 *
C7 nsp ACSOCKET ASS'Y 1713E2 CWZPM5003TW91A 1
P1 943419100460D PANEL, SUB CGR1A534Z 1 *
P2 943416100700D WINDOW, FL 1713E3 CGU1A462X 1
*
P2 943416100710D WINDOW FL
1613E3, 1713E2,
1713E1C, 1723E1C
CGU1A462Y 1 *
P3 943412100710D KNOB, VOLUME BK CBN1A263 1

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
